XBoom Coupler Skid Steer Adapter for Excavator



Click here to Buy the XBoom Coupler QC-Mate on ebay!



XBoom Coupler QC-Mate Video Animation

The XBoom Coupler® QC Mate (TM) is assembled on the IRWIN QUICK-GRIP® Heavy-Duty One-Handed Bar Clamp. Why? Because it is the best, and offers the highest clamping pressure of any one-handed bar clamp.

Clamp Info: 12" IRWIN QUICK-GRIP® Heavy-Duty One-Handed Bar Clamp, Max Opening: 12-3/4", Max clamping pressure: 600-lbs!

Then XBoom Coupler QC-Mate installs the custom Laser-Cut Jaws that enable a clamp like this to perfectly "fit" over the back-surface of both 3/8-in and 1/2-in hydraulic quick-couplers for a robust "bite" that can handle the force of the clamp!

Because of the critical nature of the assembly process, XBoom Coupler® only sells the QC-Mate(TM) as a fully assembled product, installed and ready to use on this specific IRWIN QUICK-GRIP® Clamp.

Note: XBoom Coupler® QC-Mate(TM) is constantly developing and refining its product(s), therefore specific designs and/or their specifications may change at any time without notice or obligation.

IRWIN QUICK-GRIP® Bar Clamp, is not affiliated with XBoom Coupler®, or XBoom Coupler® QC-Mate, in any way, and no Property right, Copyright or Trademark is assumed or implied. IRWIN QUICK-GRIP® is a Registered Trade Mark of IRWIN Tools. Copyright © 2018 IRWIN Tools / Stanley Black & Decker, Inc. All Rights Reserved.

Hydraulic Quick Coupler "Connect Under Pressure Hand Clamp" - Now connecting 3/8-in and 1/2-in hydraulic couplers is fast, easy and safe, even under high pressure!

Even if you don't have an XBoom Coupler®... A common problem when connecting any quick-connect hydraulic coupler between a machine and an attachment, is that line pressure can build up, from either the machine side, or in the attachment lines, thus making connection of the hydraulic couplers nearly impossible without having to relieve the line pressure. Now, the XBoom Coupler QC-Mate quickly, and safely solves that problem!

The QC-Mate "Connect Under Pressure Hand Clamp" works wherever and whenever you need to re-attach auxiliary hydraulic lines... The QC-Mate(TM) works great for almost any attachment on a Utility Tractor, Skid Steer Loader, Track Loader, Mini-Skid Steer, Mini-excavator, Midi excavator, or full size excavator!

As you can see the XBoom Coupler® QC Mate (TM) is a pair of special shaped "Clamp Jaws" that mount to a “ratcheting bar clamp.” The Clamp Jaws accommodate both 3/8-in and 1/2-in hydraulic quick couplers in a single jaw!... and is compatible with all standard Flat-Face Hydraulic Couplers and Ag Style Hydraulic Couplers. In conjunction with the “ratcheting bar clamp” it presents a compact, cost-effective and easy to use connection device with very high clamping forces!

The XBoom Coupler® QC-Mate(s) are precision laser cut from robust 13-ga steel, then bent with large structural side gussets for extreme clamping strength. Likewise, the attachment locations of the clamp jaws to the “host clamp” are designed to take advantage of their most robust molded features.

Now connecting 3/8-in and 1/2-in hydraulic couplers is fast, easy and safe, even under high pressure!

buy QC-Mate Now on EBAY

If you have a QC-Mate product question just Send Us an EMAIL

You can bookmark this page for product updates! Or, click below to follow us on FaceBook, we are very close to introducing this unique clamp!

Find Us on FaceBook

The XBoom Coupler® QC-Mate(s) are precision laser cut from robust 13-ga steel, then bent with large structural side-wall gussets for extreme integrety under clamping pressure. Likewise, the attachment locations to the “host clamp” are designed to take advantage of the clamps most robust molded features:

The Clamp Jaws accommodate all ISO standard 3/8-in and 1/2-in hydraulic quick couplers (Compatible with both Flat-Face Hydraulic Couplers and Ag Style Hydraulic Couplers):

XBoom Coupler QC-Mate Precision Laser Cut Profile

Xboom Coupler QC-Mate is 3/8-in and 1/2-in coupler compatible

3/8-in Flat-Face hydraulic quick couplers engaged in theXBoom Coupler® QC-Mate(s) Clamp Jaws and ready for attachent. (Compatible with all standard Flat-Face Hydraulic Couplers and Ag Style Hydraulic Couplers):

XBoom Coupler QC-Mate with 3/8-in hydraulic couplers engaged in the clamp

Squeeze the Heavy-Duty One-Handed Bar Clamp a few times and the 3/8-in Flat-Face hydraulic quick couplers quickly "click" together even under significant line pressure! (Compatible with all standard Flat-Face Hydraulic Couplers and Ag Style Hydraulic Couplers):

1/2-in Flat-Face hydraulic quick couplers in theXBoom Coupler® QC-Mate(s) Clamp Jaws and ready for attachent. (Compatible with all standard Flat-Face Hydraulic Couplers and Ag Style Hydraulic Couplers):

Squeeze the Heavy-Duty One-Handed Bar Clamp a few times and the 1/2-in Flat-Face hydraulic quick couplers quickly "click" together even under significant line pressure!. (Compatible with all standard Flat-Face Hydraulic Couplers and Ag Style Hydraulic Couplers):

XBoom Coupler QC-Mate with 1/2-in hydraulic couplers engaged and closed with the clamp



Connecting Hydraulic Couplers on the Arm of the Excavator for the XBoom Coupler



Connecting Hydraulic Couplers on the Arm of the Excavator for the XBoom Coupler

Don't have an XBoom Coupler®? No Problem, the QC-Mate(TM) works great for any hydraulic attachment on your excavator!:

Don't have an XBoom Coupler®? No Problem, the QC-Mate(TM) works great for almost any attachment on a Utility Tractor, Skid Steer Loader, Track Loader or Mini-Skid Steer:

Don't have an XBoom Coupler®? No Problem, the QC-Mate(TM) works great for almost any hydraulic line attachment on a Farm / AG Tractor, Utility Tractor, Skid Steer Loader, Track Loader or Mini-Skid Steer, or Walk Behind Skid Steer Loader

Note: The geometery of the XBoom Coupler® QC-Mate "mates" to the back-side of all ISO standard Quick-Connect Hydraulic Couplers with standard fittings attached to them. However, some modern skid-steers have "hydraulic blocks" that may or may not be compatible with the XBoom Coupler® QC-Mate. You need look at your specific set-up. If you have un-obstructed standard fittings going into your ISO standard Quick-Connect Hydraulic Couplers, then the XBoom Coupler® QC-Mate should work!



Click here to Buy the XBoom Coupler QC-Mate on ebay!



Hydraulic Quick Coupler "Connect Under Pressure Hand Clamp"

Now connecting hydraulic quick couplers is fast, easy and safe, even under high pressure!

A common problem when connecting any quick-connect hydraulic coupler between a machine and an attachment, is that line pressure can build up, from either the machine side, or in the attachment lines, thus making connection of the hydraulic couplers nearly impossible without having to relieve the line pressure. Now, the XBoom Coupler QC-Mate quickly, and safely solves that problem!

The QC-Mate works whenever you need to re-attach auxiliary hydraulic lines. The QC-Mate(TM) works great for almost any attachment on a Utility Tractor, Ag Tractor, Skid Steer Loader, Track Loader, Mini-Skid Steer, Mini-excavator, Midi excavator, or full-size excavator!

The XBoom Coupler® QC Mate (TM) includes a pair of special shaped "Clamp Jaws" that are robustly mounted to a “ratcheting bar clamp.” The Clamp Jaws accommodate both 3/8-in and 1/2-in hydraulic quick couplers in a single jaw! The special QC-Mate Jaws are precision laser cut from robust 13-ga steel, then bent with large structural side gussets for extreme clamping strength, and the attachment locations of the "clamp jaws" take advantage of the clamps most robust molded features.

The tool is compatible with ALL standard Flat-Face Hydraulic Couplers and Ag Style Hydraulic Couplers and presents a compact, cost-effective, and easy to use connection device with very high clamping forces!

The XBoom Coupler® QC-Mate Jaws are mounted to 12" IRWIN QUICK-GRIP® Heavy-Duty One-Handed Bar Clamp, Max Opening: 12-3/4", 600-lbs of Clamping Force!

Because of the critical nature of the assembly process, XBoom Coupler® only sells the QC-Mate(TM) as a fully assembled product, with the Clamp Jaws installed and ready to use!

Note: The Clamp Jaws need to engage the back-side of each coupler. Therefore, this device may not be compatible with some “Hydraulic Blocks” where access to both sides of the circuit are not accessible… meaning you have to have available surfaces with a “shared center-line” for the clamp to align correctly and create an "in-line" squeezing force.



The XBoom Coupler® QC-Mate is perfect for attaching the following Hydraulic Quick-Couplers and/or Universal Skid Steer Loader Attachments:

4-in-1 Bucket, Grapple, Hydraulic Breaker, Hydraulic Hammer, Cement Mixer, Concrete Claw, Concrete Crusher, Rock Crusher, Demolition Shear, Auger, Bale Handler, Telescopic Boom, Breaker, Hammer, Brush, Snow Plow, V-Plow, Snow Blower, Tree Shear, Trencher, walk-behind or micro-loaders, skid steer hydraulic couplers, skid steer flat face couplers, skid steer hydraulic coupler, skid steer hydraulic quick attach, skid steer hydraulic quick coupler, hydraulic couplers for skid steer, mini excavator hydraulic couplers, mini excavator flat face couplers, mini excavator hydraulic coupler, mini excavator hydraulic quick attach, mini excavator hydraulic quick coupler, hydraulic couplers for mini excavator... Basically anything you can put on a skid-steer, walk behind or mini excavator that has auxiliary hydraulic lines.
